Speciality:
1 Pre-filtration for the heavy polluted general draft apparatus and the air control system
2 Anti-fractured PET organic synthetic fiber
3 Large dust holding capacity ,small resistance, long service life and economical
4 No silicon, chemical resistant and anti-acidic
5 Conforming with European and American classifications standard in nonflammability
(DIN53438-F1; UI900-class 2 with flameout)
6 Applied to plank filter and foldaway filter
7 Available in paper frame ,galvanize iron frame, aluminum alloy frame and so on.
Application:
Applied to many industry such as pollution controlling ,public construction ,air-condition,
electronic, pharmacy ,food and so on.
Model | AZ-100 | AZ-150 | AZ-200 |
Material | polyester |
Thickness | 10mm | 15mm | 20mm |
Air velocity | 2.0m/s | 2.0m/s | 1.5m/s |
Initial resistance | 20Pa | 20Pa | 20Pa |
Final resistance | 125Pa | 200Pa | 200Pa |
Average arrestance | 68% | 83% | 85% |
Temperature Resistance | 100℃ | 100℃ | 100℃ |
Temperature short peaks | 120℃ | 120℃ | 120℃ |
Dust holding | 380g/m2 | 450g/m2 | 500g/m2 |
Filtration class | G2 | G2 | G4 |
Normal size | 1.0m*20m 2.0m*20m | 1.0m*20m 2.0m*20m | 1.0m*20m 2.0m*20m |
